Toro Drip In PCB-412-025 17mm Brown Surface Dripline 0.92 GPH 12 in. 250 ft (PCB-412-025)

Toro Drip In PCB-412-025 17mm Brown Surface Dripline 0.92 GPH 12 in. 250 ft

The PCB-412-025 is a 250 ft coil of Toro Drip In 17mm brown pressure-compensating surface dripline. Emitters are 0.92 GPH on 12 inch spacing, factory-installed in 0.560 inch ID by 0.660 inch OD polyethylene with a 0.050 inch wall.

Toro describes Drip In surface dripline as an at-grade landscape line with a large double-outlet cylindrical emitter. Filtration is still required. The series uses 120 mesh minimum filtration and operates from 15 to 60 psi. Toro lists a 270 ft maximum run for 12 inch PCB models at 25 psi, and 200 ft at 40 psi.

Key Specifications & Features

• SKU: PCB-412-025
• Brand: Toro
• Series: Drip In
• Coil length: 250 ft
• Emitter flow: 0.92 GPH
• Emitter spacing: 12 in.
• Tubing: 17 mm (0.560 in. ID x 0.660 in. OD)
• Wall thickness: 0.050 in.
• Color: Brown
• Placement: On-surface
• Pressure: 15 to 60 psi
• Filtration: 120 mesh minimum
• Brown 17mm pressure-compensating surface dripline for at-grade beds and shrub areas.
• 0.92 GPH emitters on 12 inch spacing, 250 ft coil.
• 0.560 in. inside diameter, 0.660 in. outside diameter, 0.050 in. wall.
• Laser-etched tubing identification, raised emitter inlets, and dual opposed outlets for air relief.
• 120 mesh minimum filtration. Operating pressure 15 to 60 psi.
• Published coil weight is 9 lb.

Frequently Asked Questions

What length and flow is the PCB-412-025?
It is one 250 ft coil of brown 17mm Drip In dripline with 0.92 GPH emitters spaced 12 inches apart.

Is this subsurface DL2000?
No. PCB-412-025 is Toro Drip In brown surface dripline for at-grade installation. DL2000 is the separate ROOTGUARD subsurface series.

What fittings fit 17mm Drip In?
Toro specs 0.560 inch ID and 0.660 inch OD. Use 17mm insert or compression fittings made for that outside diameter, not 1/2 inch drip fittings unless they are listed for 17mm.

How long can a run be?
Toro’s landscape dripline design guide lists 270 ft at 25 psi and 200 ft at 40 psi for 12 inch PCB models. Stay inside the chart for the inlet pressure you actually have.

Does the price include the full coil?
Yes. The price is for one 250 ft coil, and parcel shipping is included.
