Resideo Braukmann DS06-102-SUT-LF — 1 inch DialSet Pressure Reducing Valve
The Resideo Braukmann DS06-102-SUT-LF is a lead-free DialSet pressure reducing valve
for potable water and irrigation. It holds a steady outlet pressure when the supply pressure
is high or unsteady. The downstream dial sets static pressure from 25 to 90 psi without a gauge.
This is the 1 inch (DN25) female NPT single-union model.
Manufacturer number DS06-102-SUT-LF/U.
Key Specifications & Features
- SKU: DS06-102-SUT-LF
- Manufacturer number: DS06-102-SUT-LF/U
- UPC: 085267981767
- Brand: Resideo Braukmann
- Series: DS06 DialSet
- Connection: 1 inch female NPT, single union, internally threaded
- Outlet pressure: 25–90 psi, set on the dial
- Maximum inlet: 250 psi
- Gauge taps: 1/4" NPT, one on each side
- Strainer: Built in
- Cartridge: Balanced, noncorroding, replaceable
- Body: Lead-free bronze, fabric-reinforced diaphragm
- Temperature: 33–140°F
- Listings: ASSE 1003, CSA B356, IAPMO, NSF/ANSI 61, low-lead
Where it is used
Install the DS06-102-SUT-LF on a potable line or an irrigation point of connection that needs a
controlled downstream pressure. It is a pressure reducing valve. It does not replace a
backflow preventer. Use an expansion tank where a closed system needs one.
Frequently Asked Questions
What pipe size is the Resideo Braukmann DS06-102-SUT-LF?
1 inch female NPT (DN25), single union. The other stocked size is listed separately.
What pressure does DS06-102-SUT-LF deliver?
The dial sets static outlet pressure from 25 to 90 psi. Maximum inlet pressure is 250 psi.
1/4 inch taps on both sides accept gauges if you want to confirm the setting.
Do I need a gauge to set DS06-102-SUT-LF?
No. DialSet is marked so static pressure can be set on the dial. Gauges are optional, for checking.
Is DS06-102-SUT-LF a backflow preventer?
No. This is a pressure reducing valve. A backflow preventer is a separate assembly.
