Rain Bird RD1800 Series 6 in. SAM PRS (45 psi) Non-Potable Spray Body, Case of 50 (A37460NP-CASE)

Rain Bird RD1800 Series RD06-S-P45-NP case

Contractor case of 50 Rain Bird RD1800 Series RD06-S-P45-NP pop-up spray bodies (order number A37460NP). Each body is the 6 in. pop-up. The carton is bodies only. It is not a nozzle-installed spray head.

Specifications

• Manufacturer model RD06-S-P45-NP. Rain Bird order number A37460NP.
• 6 in. (15.2 cm) pop-up; 9 3/8 in. (23.8 cm) body height.
• 1/2 in. (15/21) NPT female inlet.
• Exposed surface diameter 2 1/4 in. (5.7 cm).
• Operating pressure 15 to 100 psi (1.0 to 6.9 bar).
• Seal-A-Matic check valve holds up to 14 ft (4.2 m) of elevation, about 6 psi. SAM models are bottom inlet.
• SAM flow-by: 0 gpm at 15 psi (1.0 bar) or greater; 0.5 gpm otherwise.
• In-stem PRS holds nozzle pressure near 45 psi (3.1 bar). 30 psi is the spray-nozzle setting. 45 psi is the rotary-nozzle setting. PRS bodies are WaterSense certified.
• Non-potable cover with purple markings and the “DO NOT DRINK” / “NO BEBA” warning.
• UV-resistant plastic body, stainless steel retraction spring, and co-molded wiper seal. Five-year trade warranty.
• Case quantity: 50 bodies. Spray nozzle is not in the carton.

Case contents

50 units per case. Planning weight for this case is 17.5 lb. Sell price is per case.

Common questions

Does this case include spray nozzles? No. These are RD06-S-P45-NP bodies only. A nozzle is not installed and is not in the carton. The body accepts Rain Bird plastic spray and rotary nozzles sold separately.

What pop-up height is this body? This RD1800 body has a 6 in. pop-up. The canister is 9 3/8 in. (23.8 cm) tall.

Does the body have a Seal-A-Matic check valve? Yes. SAM holds water in the lateral through about 14 ft of elevation change so the lowest head does not drain the pipe after the valve closes.

Is this the non-potable 45 psi body? Yes. The stem regulates to about 45 psi, and the cover is the non-potable version with purple DO NOT DRINK / NO BEBA markings.
