Rain Bird 8005 5 in. Full/Part-Circle Rotor with SAM and Stainless Steel, Case of 12 (B81300-CASE)

Rain Bird 8005 5 in. Full/Part-Circle Rotor with SAM and Stainless Steel, Case of 12 (B81300-CASE)

This carton is 12 Rain Bird 8005-SS rotors, manufacturer B81300. Rain Bird 8005 5 in. Full/Part-Circle Rotor with SAM and Stainless Steel is the single-head configuration inside the case. Rain Bird publishes this head as a 5 in. pop-up. Performance figures below are the series ranges Rain Bird prints for the nozzle set, not a single-nozzle promise.

Key Specifications

8005 Series figures below come from the Rain Bird page for this model, plus the case quantity.

• Case quantity: 12 rotors
• Manufacturer model: 8005-SS
• Manufacturer SKU: B81300
• Inlet: 1 in. NPT or BSP female
• Body: 5 in. pop-up
• Published radius range: 39 to 81 feet. Arc adjusts from 50 to 330 degrees part-circle, with 360-degree non-reversing full-circle in the same head.
• Published pressure: 50 to 100 psi
• Published flow range: 3.8 to 36.3 gpm across the nozzle set
• Published precipitation rate: 0.48 to 1.23 inches per hour
• SAM check valve: holds up to 10 feet of head
• Riser: stainless steel

How many rotors are in this case?
The case contains 12 Rain Bird 8005-SS rotors, manufacturer B81300.

What arc does this model cover?
This 8005 is a full/part-circle rotor. Rain Bird specifies part-circle adjustment from 50 to 330 degrees and 360-degree non-reversing full-circle in the same head.

Which options does this model include?
This model includes a Seal-A-Matic (SAM) check valve that holds up to 10 feet of head and a stainless steel riser. It does not include PRS, flow shut-off, or a non-potable cover.

What inlet and radius does Rain Bird publish?
Rain Bird lists a 1 in. NPT or BSP female inlet and a radius range of 39 to 81 feet for this series. Published flow is 3.8 to 36.3 gpm across the nozzle set. Match the nozzle and pressure to the site before you set spacing.
