Hunter ROAMXL-R Long-Range Receiver — Replacement Receiver for ROAM XL Remotes
The Hunter ROAMXL-R is the receiver-only unit for the Hunter ROAM XL long-range
wireless remote system. Plug it into a Hunter SmartPort® connector to enable remote manual station
operation from up to 2 miles line-of-sight when paired with a compatible ROAM XL (or legacy ICR)
transmitter. Ideal for replacing a damaged receiver without buying a full kit.
Key Specifications & Features
- SKU: ROAMXL-R
- Brand: Hunter Industries
- Product: ROAM XL Receiver Only (SmartPort wiring harness included)
- Range: Up to 2 miles (line of sight) transmitter-to-receiver
- Operating Frequency: 27 MHz
- Receiver Power: 24 VAC, 0.010 A (from controller via SmartPort)
- Addresses: 128 programmable addresses
- Stations: Manual operation of up to 240 stations
- Run Times: 1–90 minutes without overwriting automatic programs
- SmartPort Distance: Mount SmartPort up to 50 ft from controller (use shielded harness for longer runs)
- Compatibility: Hunter X-Core, X2, Pro-C, HPC, ICC2, HCC, I-Core, ACC, ACC2 (SmartPort-enabled)
- Cross-Compatible: Works with legacy ICR transmitters
- Warranty: 3 years from manufacturing date code
Compatible Controllers & Systems
Works with Hunter controllers that support a SmartPort connection, including X-Core, X2, Pro-C, HPC,
ICC2, HCC, I-Core, ACC, and ACC2. Pair with a Hunter ROAMXL-TR transmitter (or legacy ICR
transmitter) on the same address. Not compatible with ROAM LR transmitters — ROAM XL and ROAM LR use
different radio frequencies.
Frequently Asked Questions
What is included with the Hunter ROAMXL-R receiver?
The ROAMXL-R is the receiver unit only and includes the SmartPort wiring harness needed to connect to
a compatible Hunter controller. It does not include a handheld transmitter — order the ROAMXL-TR
separately if you also need the remote.
Will the ROAMXL-R work with my existing ROAM XL transmitter?
Yes. Match the programmable address on the ROAMXL-R receiver to your existing ROAM XL transmitter and
plug the receiver into the SmartPort. It also works with legacy ICR transmitters using the same addressing.
Is the Hunter ROAMXL-R compatible with the newer ROAM LR remote?
No. ROAM XL and ROAM LR operate on different radio frequencies. Use ROAMXL-R only with ROAM XL or
legacy ICR transmitters — not with ROAM LR transmitters.
Which Hunter controllers work with the ROAMXL-R?
Any Hunter controller with a SmartPort connector, including X-Core, X2, Pro-C, HPC, ICC2, HCC, I-Core,
ACC, and ACC2. Controllers without a SmartPort need a SmartPort wiring harness installed first.
