FX Luminaire PS ZDC Down Light Flat Black Finish (PS-ZDC-FB)

FX Luminaire PS ZDC Down Light — Flat Black Finish (PS-ZDC-FB)

The FX Luminaire PS-ZDC-FB is the top-mount fixed LED down light with full Zone/Dim/Color (ZDC) Luxor control in a sleek Flat Black powder coat finish. The PS is the next generation of fixed-mount landscape down lights — compact at just 3.2" diameter and 3.3" height — delivering 174 lumens of tunable RGBW color light with infinite color mixing capability via the Luxor app.

Key Specifications & Features

• SKU: PS-ZDC-FB
• Brand: FX Luminaire
• Control: ZDC — Zone / Dim / Color with Luxor®
• Finish: Flat Black (FB) — two-layer marine-grade powder coat
• Diameter: 3.2" / 8.1 cm
• Height: 3.3" / 83 mm
• Delivered Lumens: 174 lm
• Input Power: 9.1W / 11.0 VA
• Input Voltage: 11–15V AC/DC low voltage
• LED Board: Cree® integrated ZDC module (RGBW 30,000+ colors)
• Material: Die-cast C360 brass housing
• IP Rating: IP64
• Rated Life: 50,000 hours (L70 B10)
• Lead Wire: 18 AWG, 3.6' (1.1 m) length
• Includes: Fixture, ZDC LED board, 10' lead wire, mounting bracket
• Certifications: UL, CE, RoHS, IP64, IDA

Frequently Asked Questions

What does ZDC mean on the FX Luminaire PS-ZDC-FB?
ZDC stands for Zone / Dim / Color — FX Luminaire's full Luxor® control tier. With ZDC you can independently zone, dim 0–100%, and dial in any of 30,000+ RGBW colors from the Luxor app. The PS-ZDC-FB is the Flat Black version of this high-spec fixture.

Is a transformer required for the PS-ZDC-FB?
Yes. The PS-ZDC-FB requires a 12V low-voltage transformer. For ZDC color/dimming control you must use a Luxor ZDC-compatible FX Luminaire transformer (e.g. LUX-300-M, LUX-600-SS). At 11.0 VA per fixture, plan your transformer load accordingly.

Can I use beam angle lenses with the PS-ZDC-FB?
Yes. The PS is compatible with FX Luminaire's interchangeable beam angle lenses: Diffuser 18° (pre-assembled), Flood 30–32° (1 notch), and Wide Flood 56–58° (2 notches). MR-16 sized accessories (1.95" dia.) also fit.

What is the PS-ZDC-FB made of?
The housing is die-cast C360 brass with a two-layer marine-grade anodization and Flat Black powder coat. Stainless steel mounting brackets and fasteners ensure long-term corrosion resistance in all outdoor environments.
