How to Read a Sprinkler Nozzle Chart: GPM, Radius, and Pressure

What a Nozzle Chart Tells You

Nozzle charts list flow (GPM) and radius at a reference pressure—usually 30 or 45 psi. They help you match precipitation across mixed heads so one zone waters evenly.

Pressure Changes Everything

If your field pressure is higher than the chart baseline, throws and GPM increase; if lower, expect shorter throws and potential misting. Use a reliable gauge at a head and adjust the pressure regulator or choose a different nozzle color.

Matched Precipitation for Rotors and Sprays

Mixed head types on one valve is a common mistake. When you must mix, convert precipitation rates mathematically or split zones. Charts from brands like Rain Bird and Hunter make that math easier.

Practical Field Tips

Mark each head with its nozzle ID, photograph the layout, and keep spare nozzles in your truck. That habit speeds service calls and reduces callbacks.

Frequently Asked Questions

Why are my dry spots random?

Usually pressure variance, clogged screens, or unmatched nozzles—not bad luck.

Can I upsize a nozzle for more distance?

Sometimes, but you may exceed design flow and starve other heads on the same circuit.
